The P500 is the most powerful motor we build: 7500 W on a 48 V pack, 8000 W on a 72 V pack, and a stepless throttle that takes you from a slow crawl along a weed line to 30 km/h on open water.
One motor, three battery setups
The P500 accepts anything from 20 V to 72 V, so the same motor works with the pack you already own. It reads the input and gives you what that pack can deliver:
- 24 V pack – 2200 W, around 1500 rpm at the propeller.
- 48 V pack – 7500 W, around 3000 rpm. This is the setup most buyers run.
- 72 V pack – 8000 W, for the last few km/h.
Start on two batteries and add two more when you want more speed. Nothing else on the motor has to change.
Why brushless matters
- Longer run time – less energy is lost as heat, so more of your battery reaches the propeller.
- Nothing to wear out – no brushes, no commutator, no mid-season rebuild.
- Quieter – you hear the water, not the motor.
- Torque at low speed – which is where trolling actually happens.
Specifications
| Motor type | Brushless, transom mount |
|---|---|
| Maximum power | 2200 W on a 24 V pack, 7500 W on a 48 V pack, 8000 W on a 72 V pack |
| Working voltage | 20–72 V DC |
| Maximum current | 90 A at 24 V, 155 A at 48 V, 110 A at 72 V |
| Propeller speed | 1500 rpm at 24 V, 3000 rpm at 48 V |
| Speed control | Stepless (CVT) |
| Recommended boat length | 3–5 m |
| Typical speed | 10–30 km/h, depending on hull, load and conditions |
| Water type | Fresh and salt water |
| Weight | 23 kg, packed |
| Package size | 128 × 40 × 20 cm |
| Warranty | 2 years for private buyers in the EU |
What you get
The motor with its transom bracket and propeller fitted, the power cables, and a printed manual. Batteries are not included — the P500 runs on a 24 V, 48 V or 72 V deep-cycle pack with a matching charger.
Delivery and returns
We ship from our own stock. The estimated delivery window for your country is shown on this page and again at checkout. You get a tracking number as soon as the parcel leaves. Unused motors can be returned within 14 days of delivery.
